Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
3-6-5-2 Max Setpoint
Selection of upper
limit value for
setpoint monitoring
100 100 3-5-1-2 100 3-2-2-1 Customer -
3-6-5-3 Setp Wrn TDly
Selection of time
delay for setpoint
monitoring
5 5 0 60 s Customer -
3-6-5-4 Setp Wrn Func
Selection of setpoint
monitoring function
1 1 - - - Customer No Function
Warning
Stop & Trip
3-6-6 Feedback Warn
Submenu
- - - - - - -
3-6-6-1 Feedbk Lo Limit
Selection of low
limit value for actual
value monitoring
0 0 0 3-6-6-2 3-2-2-1 Customer -
3-6-6-2 Feedbk Hi Limit
Selection of upper
limit value for actual
value monitoring
100 100 3-6-6-1 9999 3-2-2-1 Customer -
3-6-6-3 Fdbk Wrn TDly
Selection of time
delay for actual
value monitoring
5 5 0 60 s Customer -
3-6-6-4 Fdbk Wrn Func
Selection of actual
value monitoring
function
1 1 - - - Customer No Function
Warning
Stop & Trip
3-7 Digital IN/OUT
Menu for digital inputs and outputs
3-7-1 Digital IN 2-5
Submenu for
displaying digital
inputs 2 to 5
- - - - - - -
3-7-1-2 Dig IN 2 Fnc
Selection of
function of digital
input 2
7 3 - - - Customer Selection list I
(⇨ Section 10.1
Page 129)
3-7-1-3 Dig IN 3 Fnc
Selection of
function of digital
input 3
10 10 - - - Customer Selection list I
(⇨ Section 10.1
Page 129)
3-7-1-4 Dig IN 4 Fnc
Selection of
function of digital
input 4
9 9 - - - Customer Selection list I
(⇨ Section 10.1
Page 129)
3-7-1-5 Dig IN 5 Fnc
Selection of
function of digital
input 5
2 2 - - - Customer Selection list I
(⇨ Section 10.1
Page 129)
3-7-2 Digital OUT 1
Submenu for display
of digital output 1
- - - - - - -
3-7-2-1 Dig OUT 1 Fnc
Selection of
function of digital
output 2
31 31 - - - Customer Selection list II
(⇨ Section 10.1
Page 129)
