Description Design Mat. No. [kg]
(STC 265)
(152)
Size 11 - 22 kW/PumpDrive, size C 48897645 9.7
For mounting PumpDrive to
KSB Movitec 90 pump sets
Including connection cable
and bolts/screws
The adapter is mounted on
the pump. The holes for
fastening the adapters are
not drilled in the pump at
the factory for retrofit
configurations.
Size 5.5 - 7.5 kW/PumpDrive, size B 48897646 5.1
Size 11 - 22 kW/PumpDrive, size C 48897647 8.5
Size 30 - 37 kW/PumpDrive, size D 48897648 23
Size 45 kW/PumpDrive, size D 48897652 23
Table 122: Accessories – Connection cables
Description Design Mat. No. [kg]
740
Ferrit
20
100
100
30
700
30
120
20
M4
M4
M4
Connection cable for
motors, Shielded;
includes cable for
connecting the PTC
sensor, halogen-free,
price per metre
≤ 4 kW: 4 x 2,5 mm² + PTC 47117918 0.3
900
160
20
M5
12020
M6
40
940
40
11 - 22 kW: Cable 4 x 10 mm² + 2 x 1
mm²
47117919 0.3
1200
M8
300
220
200
1320
60
220
M8
60
200
> 30 kW: 4 x 25 mm² + 2 x 1 mm² 47117920 0.3
12.2.4 Adapter for wall and cabinet mounting
The adapter can be used for wall mounting as well as for control cabinet mounting
and is included in the KSB scope of supply as standard.
