6.2.1 LED traffic light function
The LED traffic light function provides information about the current PumpDrive
operating status.
Table 31: LED description
LED Description
Red
One or more than one alert is active
Amber
One or more than one warning is active
Green
Steady light: Trouble-free operation
Flashing light: Trouble-free operation at active master
control panel in a multiple pump configuration
6.2.2 Graphical display
The graphical display breaks down into 6 areas.
3-1-1-1
OFF
B-HMI-C
STOP
Grund-Einstell
Sprache
LCD-Beleuchtung
Leuchtdauer
1
2
3
4
5
6
Fig. 23: Graphical display (example)
Table 32: Description of display
Item Description Explanation
1 Parameter No. Displays the selected parameter No.
2 Main menu selection Displays the main menu selected
▪ Operation
▪ Diagnosis
▪ Settings
▪ Information
3 Parameter selection list List of selectable parameters/parameter information
4 Operating mode Displays the current operating mode
▪ Man
▪ OFF
▪ Auto
5 Model Displays the model, e.g. A-HMI-C
PumpDrive model
A = Advanced
B = Basic
HMI = with control panel
Access level
C = Customer
S = Service
N = No login
Pump selected Pump selected
▪ Pump 1
▪ Pump 2
▪ ...
▪ Pump 6
6 Operating status Display of current operating status
6 Operation
