KSB PumpDrive - 7.2.1.10 Dry running protection and protection against hydraulic blockage (Advanced function)

Table 73: Parameters for dry running protection and protection against hydraulic blockage
Parameter Description Possible settings Factory setting
3-12-2-1 Start learning profile OFF
Start
OFF
3-12-2-2 P % @ 30 % fmax 0 ... 110,00 kW 0
3-12-2-3 P % @ 40 % fmax 0 ... 110,00 kW 0
3-12-2-4 P % @ 50 % fmax 0 ... 110,00 kW 0
3-12-2-5 P % @ 60 % fmax 0 ... 110,00 kW 0
3-12-2-6 P % @ 70 % fmax 0 ... 110,00 kW 0
3-12-2-7 P % @ 80 % fmax 0 ... 110,00 kW 0
3-12-2-8 P % @ 90 % fmax 0 ... 110,00 kW 0
3-12-2-9 P % @ 100 % fmax 0 ... 110,00 kW 0
3-12-2-10 Learn time 0..100 (s) 30 s
3-12-2-11 Learning measurement
error
0..100 % 5 %
3-12-4-7 Load curve reduction
for hydraulic blockage
(100 % – No reduction)
0..100 % 85 %
3-12-4-8 Time delay for hydraulic
blockage
0..1000 (s) 10 s
3-12-4-9 Load curve reduction
for dry running (100 %
– No reduction)
0..100 % 70 %
3-12-4-10 Time delay for dry
running
0.1000 (s) 5 s
3-12-4-11 Enable/disable dry
running function
Disabled
Enabled
Enabled
7.2.2 Functions based on pump characteristic curves
7.2.2.1 Matching PumpDrive to the pump (for PumpDrive Advanced only)
If PumpDrive is not pre-configured at the factory, the pump characteristic curve is
defined for PumpDrive using 6 Q, H, and P data points. The following illustration
shows the parameters of the respective data points using a pump characteristic curve
as an example. The input steps of the parameters are designated 1 to 4.
