KStar KSH-5k-48 User Manual

36
Interface Description
This interface displays power generation
for the month
（
KWH
）
;
PV power generation;
Grid-connection power generation;
Power consumption of load and inverter;
PressESC button to return to statistics
interface.
⑦ The year
Interface Description
This interface displays power generation
for the year
（
KWH
）
;
PV power generation;
Grid-connection power generation;
Power consumption of load and inverter;
Press ESC button to return to statistics
interface.
⑧ Gross generation
Interface Description
This interface displays gross power
generation;
PV power generation;
Grid-connection power generation;
Power consumption of load and inverter;
Press ESC button to return to statistics
interface.
8.4 Restart
Interface Description
Prompt: Restart the machine for
work-related settings to take effect. It will
return to the corresponding working
interface within 2 seconds.
9.Alarm code and error code
（1）Alarm code
Alarm code
Codes
Chinese description English description
--E-MONTH--
PV：0.0KWH
GRID:0.0KWH
CNSUM：0.0KWH
--E-YEAR--
PV：0.0KWH
GRID:0.0KWH
CNSUM：0.0KWH
--E-TOTAL-
PV：0.0KWH
GRID:0.0KWH
CNSUM：0.0KWH
Please Restart!

KStar KSH-5k-48 Specifications

General

Model	KSH-5k-48
Rated Power	5000 W
Input Voltage	48 V
Output Voltage	230 V
Output Frequency	50/60 Hz
Efficiency	>90%
Protection Degree	IP65
Input Voltage Range	40-60 V
Output Waveform	Pure Sine Wave
Rated AC Power	5000 W
Communication	RS485
Protection Features	Over Temperature Protection
MPPT Voltage Range	120-450 V
