22 TECHNICAL DATA 132
Throttle slide 7 with cut-out
Slide stop -
22.10.5 250 EXC EU, 250 EXC Six Days EU
Carburetor type KEIHIN PWK 36S AG
Carburetor identification number FK028
Needle position 2nd position from top
Jet needle N84K (N2ZW / N2ZH / N2ZJ)
Main jet 110 (172/175)
Idling jet 38x38 (38/40)
Starting jet 50 (85)
Idle air adjusting screw
Open 1.5 turns
Throttle slide 7 with cut-out
Slide stop Present
22.10.6 250 EXC AU
Carburetor type KEIHIN PWK 36S AG
Carburetor identification number 3600
Needle position 1. Position from top
Jet needle N3CJ (N8RG / N8RH / N2ZH / N2ZJ / N2ZW)
Main jet 160 (170/172/175)
Idling jet 35 (38/40)
Starting jet 85
Idle air adjusting screw
Open 3.5 turns
Throttle slide 7 with cut-out
Slide stop Present
22.10.7 250 XC‑W US
Carburetor type KEIHIN PWK 36S AG
Carburetor identification number BZ6
Needle position 3rd position from top
Jet needle N2ZW (N2ZH / N2ZJ)
Main jet 175 (172)
Idling jet 38 (40)
Starting jet 85
Idle air adjusting screw
Open 2.0 turns
Throttle slide 7 with cut-out
Slide stop -
22.10.8 300 EXC EU, 300 EXC Six Days EU
Carburetor type KEIHIN PWK 36S AG
Carburetor identification number FK029
Needle position 2nd position from top
Jet needle N84K (N8RG / N8RH)
Main jet 115 (170/172/175)
Idling jet 38X38 (35)
Starting jet 50 (85)
Idle air adjusting screw

KTM 200 XC-W Specifications

General

Starter	Electric Starter
Transmission	6-speed
Fuel System	Keihin PWK 36S AG
Ignition	Kokusan
Rear Suspension	WP Xplor PDS shock absorber
Front Brake	Disc brake
Rear Brake	Disc brake
Ground Clearance	370 mm
Seat Height	960 mm
Engine Type	2-stroke
Bore x Stroke	64.0 mm x 60.0 mm
