KTM 2014 1190 Adventure User Manual

16 ELECTRICAL SYSTEM 177
– After the last black ignition key has been activated, insert the orange programming
key into the ignition.
– Switch on the ignition by turning the orange programming key to the ON position .
The immobilizer indicator lamp flashes according to the number of func-
tional black ignition keys including the orange programming key.
– Switch off the ignition by turning the orange programming key to the OFF position .
– Pull out the orange programming key.
Info
Activation of the ignition key is finished.
To activate four black ignition keys:
– Press the emergency OFF switch to the position ON .
– Insert the orange programming key in the ignition lock.
– Switch on the ignition by turning the orange programming key to the ON position .
Immobilizer indicator lamp lights up.
– Switch off the ignition by turning the orange programming key to the OFF position .
– Pull out the orange programming key.
– Insert the black ignition key in the ignition lock.
– Switch on the ignition by turning the black ignition key to the position ON .
Immobilizer indicator lamp lights up.
– Switch off the ignition by turning the black ignition key to the position OFF .
– Remove the black ignition key.
– If three other black ignition keys are to be activated, repeat the last steps with the
respective ignition key.

KTM 2014 1190 Adventure Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	12.5:1
Torque	125 Nm @ 7500 rpm
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 19
Rear Tire	170/60 ZR 17
Dry Weight	217 kg
Fuel Capacity	23 liters
Power	150 hp (110 kW) @ 9500 rpm
Clutch	PASC slipper clutch, hydraulically operated
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9ME Combined ABS
Seat Height	860 mm
