11 SERVICE WORK ON THE CHASSIS
50
11.13 Lubricating the steering head bearing
H02387-01
– Remove the lower triple clamp. ( p. 45)
– Install the lower triple clamp. ( p. 46)
Info
The steering head bearing is cleaned and lubricated in
the course of removal and installation of the lower triple
clamp.
11.14 Removing the start number plate
E01955-10
–
Remove screw
1
. Swivel the start number plate to one side.
– Unhook the start number plate from the brake line and remove
it.
11.15 Installing the start number plate
E01956-10
– Position the brake line in holders on the start number plate.
–
Position the start number plate. Mount and tighten screw
1
.
The holding lugs engage in the fender.
11.16 Removing front fender
Preparatory work
– Remove the start number plate. ( p. 50)
