SERVICE WORK ON THE CHASSIS 11
61
V01449-10
–
Unplug connector
1
of the fuel pump.
– Pull the fuel tank breather hose off the fuel tank lid.
–
Clean quick release coupling
2
thoroughly with compressed
air.
Info
Under no circumstances should dirt enter into the fuel
line. Dirt in the fuel line clogs the injection valve!
V01450-10
–
Disconnect the quick release coupling.
Info
Remaining fuel may flow out of the fuel hose.
–
Mount wash cap set
A
.
Wash cap set (81212016100)
E01968-10
–
Remove screws
3
with the collar bushings.
K01034-10
–
Remove screw
4
with the rubber bushing.
F01542-10
– Pull both spoilers laterally off the radiator and lift off the fuel
tank.
