ROTEX
®
GS
Operating/mounting instructions
KTR-N
Sheet:
Edition:
45510 EN
2of36
15
Please note protection
mark ISO 16016.
Drawn: 15.10.12 Pz Replaced for: KTR-N valid from 08.02.12
Verified: 29.10.12 Pz Replaced by:
ROTEX
®
GS is a plug-in shaft coupling for measuring technology and automatic control
engineering. It is able to compensate for shaft misalignment produced by, as an example,
inaccuracies in production, thermal expansion, etc.
With the designing of our ROTEX
®
GS coupling, the engineering standards and regulations, in
particular DIN EN 12100, part 2 as well as DIN EN ISO 13849, part 1 and 2 „Safety of
machines” have been taken into account.
Table of Contents
1
Techni
cal Data
2
Hin
ts
2.1 Coupling Selection
2.2 General Hints
2.3 Safety and Advice Hints
2.4 General Hint to Danger
2.5 Proper Use
3
Storage
4
Assembly
4.1 Hub Types
4.2 Coupling Components
4.3 Hints for Assembly
4.4 Hint for Finish Bore
4.5 Assembly of Hubs (Types 1.0, 1.1 and 1.2)
4.6 Assembly of Clamping Hubs
(Types 2.0, 2.1, 2.5, 2.6, 2.8, 2.9, 7.5, 7.6, 7.8 and 7.9)
4.7 Assembly of Clamping Ring Hubs (Types 6.0, 6.0 steel, 6.0 light and 6.5)
4.8 Assembly of Expansion Hubs (Type 9.0)
4.9 Displacements – Alignment of the Couplings
4.10 Spares Inventory, Customer Service Addresses
5
Enclosure A
Hints and Instructions Regarding the Use in Hazardous Areas
5.1
Use in Hazardous Areas According to the Regulations
5.2
Control Intervals for Couplings in Hazardous Areas
5.3 Approximate Values of Wear
5.4
Permissible Coupling Materials in the Hazardous Area
5.5
Marking of Coupling for Hazardous Area
5.6 Starting
5.7 Breakdowns, Causes and Elimination
5.8 EC Certificate of Conformity according to the EC Standards 94/9/EC
dated 23.03.1994
