5 Enclosure A
Hints and Instructions Regarding the Use in Hazardous Areas
Available types:
a) Hubs with feather key or CLAMPEX
®
clamping set or clamping ring hubs
• 1.0 Hub with feather key and thread for setscrews
• 2.1 Clamping hub single slot with feather key
• 2.6 Clamping hub double slot with feather key
• 2.9 Clamping hub with axial slot with feather key
• 4.1 with CLAMPEX
®
clamping set KTR 200
• 4.2 with CLAMPEX
®
clamping set KTR 250
• 6.0 Clamping ring hub
• 6.0 Clamping ring hub light
• 6.0 P Precision clamping ring hub
• 6.5 Clamping ring hub
(Hint: external clamping screws)
• 7.6 Split clamping hub with feather key for double-cardanic combinations
• 7.9 Split clamping hub with feather key for single-cardanic combinations
• Type DKM with hubs corresponding to the aforementioned details
b) Hubs without feather key (category 3 only)
• 1.1 Hub without feather key, with thread for setscrews
• 2.0 Clamping hub single slot without feather key
• 2.5 Clamping hub double slot without feather key
• 2.8 Clamping hub with axial slot without feather key
• 7.5 Split clamping hub without feather key for double-cardanic combinations
• 7.8 Split clamping hub without feather key for single-cardanic combinations
• Type DKM with hubs corresponding to the aforementioned details
ROTEX
®
GS type DKM only with spacer from steel or aluminium wrought products with a yield stress
R
p0,2
≥ 250 N/mm
2
.
