KTR ROTEX GS - Spares Inventory, Customer Service Addresses

KTR Kupplungstechnik
GmbH
D-48407 Rheine
ROTEX
®
GS
Operating/mounting instructions
KTR-N
Sheet:
Edition:
45510 EN
27of36
15
Please note protection
mark ISO 16016.
Drawn: 15.10.12 Pz Replaced for: KTR-N valid from 08.02.12
Verified: 29.10.12 Pz Replaced by:
4
Assembly
4.9
Displacements
–
Alignment of the Couplings
Table14: Displacements – Type DKM
Size
max. axial
displacement
∆Ka [mm]
max. radial displacement
∆Kr [mm]
max. angular displacement
∆Kw [degrees]
80
ShA-GS
92
ShA-GS
95/98
ShA-GS
64
ShD-GS
72
ShD-GS
80
ShA-GS
92
ShA-GS
95/98
ShA-GS
64
ShD-GS
72
ShD-GS
5 +0,4 / -0,4 0,15 0,14 0,13 - - 1,1 1,0 0,9 - -
7 +0,6 / -0,6 0,23 0,21 0,19 0,17 - 1,1 1,0 0,9 0,8 -
9 +0,8 / -0,8 0,29 0,26 0,24 0,21 - 1,1 1,0 0,9 0,8 -
12 +0,9 / -0,9 0,35 0,32 0,29 0,25 - 1,1 1,0 0,9 0,8 -
14 +1,0 / -1,0 0,40 0,37 0,33 0,29 - 1,1 1,0 0,9 0,8 -
19 +1,2 / -1,0 0,49 0,45 0,41 0,36 - 1,1 1,0 0,9 0,8 -
24 +1,4 / -1,0 - 0,59 0,53 0,47 0,42 - 1,0 0,9 0,8 0,7
28 +1,5 / -1,4 - 0,66 0,60 0,53 0,46 - 1,0 0,9 0,8 0,7
38 +1,8 / -1,4 - 0,77 0,69 0,61 0,54 - 1,0 0,9 0,8 0,7
42 +2,0 / -2,0 - 0,84 0,75 0,67 0,59 - 1,0 0,9 0,8 0,7
48 +2,1 / -2,0 - 0,91 0,82 0,73 0,64 - 1,0 0,9 0,8 0,7
55 +2,2 / -2,0 - 1,01 0,91 0,81 0,71 - 1,0 0,9 0,8 0,7
The permissible displacement figures of the flexible ROTEX
®
GS couplings mentioned are general standard values taking into
account the load of the coupling until the rated torque T
KN
of the coupling and an ambient temperature of +30 °C.
4.10
Spares Inventory, Customer Service Addresses
A basic requirement to guarantee the operational readiness of the coupling is a stock of the most important spare
parts on site.
Contact addresses of the KTR partners for spare parts and orders can be obtained from the KTR homepage
under www.ktr.com.

AT T E N T I O N !
KTR does not assume any liabilities or guarantees regarding the use of spare parts and
accessories which are not provided by KTR and for the damages resulting herefrom.
