5 Enclosure A
Hints and Instructions Regarding the Use in Hazardous Areas
5.1 Use in Hazardous Areas According to the Regulations
Conditions of operation in hazardous locations
ROTEX
®
GS couplings are suitable for the use according to EC standard 94/9/EC.
1. Industry (with the exception of mining)
• device class II of category 2 and 3 (coupling is not approved for device class 1)
• media class G (gases, fogs, steams), zone 1 and 2 (coupling is not approved for zone 0)
• media class D (dusts), zone 21 and 22 (coupling is not approved for zone 20)
• explosion class IIC (explosion class IIA and IIB are included in IIC)
Temperature class:
Temperature class
Ambient or operating
temperature T
a
Max. surface temperature
T4, T3, T2, T1 - 30 °C to + 90 °C
1)
110 °C
2)
T5 - 30 °C to + 80 °C 100 °C
T6 - 30 °C to + 65 °C 85 °C
Explanation:
The maximum surface temperatures result from each the maximum permissible ambient or operating temperature T
a
plus the
maximum temperature increase ∆T of 20 K which has to be taken into account.
1) The ambient or operating temperature T
a
is limited to + 90 °C due to the permissible permanent operating temperature of
the elastomers used.
2) The maximum surface temperature of 110 °C applies for the use in locations which are potentially subject to dust explosion,
too.
Operating temperature of the spider:
Spider hardness
(Shore)
Permissible temperature range [°C]
Permanent temperature
Max. temperature short-term
80 Sh A-GS -50 to +80 -60 to +120
92 Sh A-GS -40 to +90 -50 to +120
95/98 Sh A-GS -30 to +90 -40 to +120
64 Sh D-H-GS -50 to +120 -60 to +150
64 Sh D-GS -20 to +110 -30 to +120
72 Sh D-H-GS -50 to +120 -60 to +150
72 Sh D-GS -20 to +110 -30 to +120
!
C A U T I O N !
In case that the operating temperature changes it is absolutely necessary to verify the
coupling selection (see ROTEX
®
GS catalogue).
2. Mining
Device class I of category M2 (coupling is not approved for device category M1).
Permissible ambient temperature - 30 °C to + 90 °C.
