PERIODIC SERVICE46
ENGLISH
BOiling
To avoid serious injury or death:
A Be sure to stop the engine and remove the key
before oiling.
Oil the following locations.
BChecking Wheel Bolt Torque
To avoid serious injury or death:
A Never operate machine with a loose rim, wheel,
or axle.
A Any time bolts and nuts are loosened, retighten
to specified torque.
A Check all bolts and nuts frequently and keep
them tight.
Check wheel bolts and nuts regularly especially when
new. If they are loose, tighten them as follows.
(1) Seat adjuster
(1) Throttle cable
(1) Nut: 48.1 to 55.9 N-m (4.9 to 5.7 kgf-m)
(2) Nut: 69.0 to 73.0 N-m (7.0 to 7.4 kgf-m)
To Next Page
