2-S5
GR1600EC2, WSM
TRANSAXLE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-9.)
W1012736
Item N·m kgf·m ft-lbs
Brake plate mounting screw 34 to 40 3.47 to 4.07 25.1 to 29.5
Universal joint mounting screw 9.8 to 11.3 1.00 to 1.15 7.23 to 8.33
Transaxle mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Hydrostatic transmission mounting screw 23.5 to 27.5 2.4 to 2.8 17.3 to 20.3
Hydrostatic transmission mounting screw 2 17.7 to 20.6 1.8 to 2.1 13.1 to 15.2
Center section mounting hex. socket head screw 17.7 to 20.6 1.8 to 2.1 13.1 to 15.2
By-pass valve plug 15.0 1.53 11.1
Check valve plug 30.0 3.06 22.1
PTO clutch assembly mounting screw 17.7 to 20.6 1.8 to 2.1 13.1 to 15.2
Beam mounting screw 17.7 to 20.6 1.8 to 2.1 13.1 to 15.2
Transaxle case screw 7.8 to 8.8 0.8 to 0.9 5.8 to 6.5
42T gear mounting screw 9.8 to 11.3 1.00 to 1.15 7.23 to 8.33
To Next Page
