3-S1
GR1600EC2, WSM
BRAKES
1. TROUBLESHOOTING
W1014322
Symptom Probable Cause Solution
Reference
Page
Insufficient Braking
Force
Brake pedal free travel excessive Adjust 3-S4
Brake shoe worn Replace 3-S8
Brake drum worn Replace 3-S8
Grease or oil on brake shoe Replace 3-S8
Brake Drags Brake pedal free travel too small Adjust 3-S4
Brake spring weaken or broken Replace 3-S8
Heavy Brakes Brake pedal rusted Repair or replace 3-S7
Brake cam lever rusted Replace 3-S8
To Next Page
