Specifications - 210 RT120Q Operator’s Manual
H1140 Saw
H1140 Saw
Dimensions U.S. Metric
A Trench depth 40.5 in 1.03 m
Trench width 4.5, 6, 8 in 115,150,
203 mm
D Transport height - attachment 130 in 3.3.m
Height - wheel on ground 102 in 2.6 m
L2’ Overall length - wheel on ground 122.5 in 3.1 m
J Ground clearance at wheel 27 in 700 mm
A3 Angle of departure 24° 24°
Attachment weight 5900 lb 2675 kg
t37om049w.eps
L2L2
DD
JJ
AA
A3A3
