RT120Q Operator’s Manual Controls - 45
Graphic Display
Ground Drive Neutral Indicates ground drive
controls in neutral position.
Main Menu Press soft key to return to
previous screen.
Press center soft key to display gauge
screen.
Gauge Display Press the soft key on screen
icon to select.
Engine stop Press to stop engine from
backhoe operator’s station.
Switch must be raised (reset) to allow
engine starting.
Item Description Notes
