RT120Q Operator’s Manual Controls - 47
Right Console
Item Description Notes
1. Backfill blade lift/tilt
control
Backfill blade mode:
• To lower, move forward.
• To float, move forward to
end.
• To raise, move backward.
• To tilt right side down,
move right.
• To tilt left side down,
move left.
Reel winder control Reel winder mode:
• To unwind, move forward.
• To wind, move backward.
• To lower reel winder arm,
move right.
• To raise reel winder arm,
move left.
2. Rear steer switch To move rear tracks left,
press left.
To move rear tracks right,
press right.
NOTICE:
• Tracks move when you press the
switch. To stop movement,
release switch.
• Visually verify track position
3. Rear steer manual/auto
switch
To center tracks, press right.
To manually steer rear tracks,
press left.
Use manual mode and the manual
rear steer switch to bypass auto
mode.
