S-18
07-E3B SERIES, WSM
ENGINE
3. TIGHTENING TORQUES
Use a torque wrench to tighten the screws, bolts and nuts to the specified torque. Tighten the screws, bolts and
nuts used, such as on the cylinder head in the correct sequence and torque.
[1] TIGHTENING TORQUES OF SCREWS, BOLTS AND NUTS FOR GENERAL
USE
If the tightening torque is not specified, refer to the table below for the none specified torques values.
W10345420
Indication on
top of bolt
No-grade or 4T 7T
Indication on
top of nut
No-grade or 4T
Unit N·m kgf·m lbf·ft N·m kgf·m lbf·ft
M6 7.9 to 9.3 0.80 to 0.95 5.8 to 6.8 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
M8 18 to 20 1.8 to 2.1 13 to 15 24 to 27 2.4 to 2.8 18 to 20
M10 40 to 45 4.0 to 4.6 29 to 33 49 to 55 5.0 to 5.7 37 to 41
M12 63 to72 6.4 to 7.4 47 to 53 78 to 90 7.9 to 9.2 58 to 66
To Next Page
