Kubota WSM 07-E3B Series User Manual

G-27
07-E3B SERIES, WSM
G GENERAL
[10] CHECK POINTS OF EVERY 1 YEAR
Changing Engine Oil
CAUTION
• Be sure to stop engine before changing engine oil.
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. To drain the used oil, remove the drain plug (1) at the bottom of
the engine and drain the oil completely.
4. Screw the drain plug (1).
5. Fill new oil up to upper line on the dipstick (2).
IMPORTANT
• When using an oil of different maker or viscosity from the
previous one, remove all of the old oil.
• Never mix two different types of oil.
• Engine oil should have properties of API classification CF
(See page G-6).
• Use the proper SAE Engine Oil according to ambient
temperature.
W1036031
Replacing Air Cleaner Element
1. Remove used air cleaner element.
2. Replace new air cleaner element.
NOTE
• The air cleaner uses a dry element. Never apply oil to it.
• Do not operate the engine with filter element removed.
W1020554
Above 25 °C (77 °F)
SAE 30 or SAE 10W-30
SAE 15W-40
0 °C to 25 °C (32 °F to 77 °F)
SAE 20 or SAE 10W-30
SAE 15W-40
Below 0 °C (32 °F)
SAE 10W or SAE 10W-30
SAE 15W-40
Engine oil capacity
V2607-DI-E3B
V2607-DI-T-E3B
10.2 L
2.69 U.S.gals
V3007-DI-T-E3B
V3307-DI-T-E3B
11.2 L
2.96 U.S.gals
Tightening torque Drain plug
45 to 53 N·m
4.5 to 5.5 kgf·m
33 to 39 lbf·ft
(1) Drain Plug
(2) Dipstick
(3) Oil Filler Plug
(a) Upper Line
(b) Lower Line
A : V2607-DI-E3B / V2607-DI-T-E3B
B : V3007-DI-T-E3B / V3307-DI-T-E3B
KiSC issued 06, 2020 A

Kubota WSM 07-E3B Series Specifications

General

Brand	Kubota
Model	WSM 07-E3B Series
Category	Engine
Language	English
