S-20
07-E3B SERIES, WSM
ENGINE
[V2607-DI-E3B / V2607-DI-T-E3B]
W1330341
[V3007-DI-T-E3B / V3307-DI-T-E3B]
W1335256
Item
Dimension x
Pitch
N·m kgf·m lbf·ft
Rocker arm bracket screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
*Cylinder head mounting screw
[Head gasket parts number: 1J700-
03312, 1J700-03322, 1J700-03332]
M13 x 1.25 147 to 156 15.0 to 16.0 109 to 115
*Cylinder head mounting screw
[Head gasket parts number: 1J700-
03313, 1J700-03323, 1J700-03333]
M13 x 1.25 155 to 165 15.8 to 16.8 114 to 121
Injection pump gear mounting nut
(left-handed screw)
M16 x 1.5 -LH 93.2 to 102 9.50 to 10.5 68.8 to 75.9
Oil cooler joint screw M20 x 1.5 64 to 73 6.5 to 7.5 47 to 54
Front cover mounting screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Flywheel housing mounting screw M12 x 1.25 78 to 90 7.9 to 9.2 58 to 66
Idle gear mounting screw M10 x 1.25 49 to 55 5.0 to 5.7 37 to 41
*Connecting rod screw
[Serial No. : 8G0001 to 9K9999]
M8 x 1.0 45 to 49 4.5 to 5.0 33 to 36
*Connecting rod screw
[Serial No. : 9L0001 and above]
M8 x 1.0 41 to 45 4.1 to 4.6 30 to 33
*Crankcase 2 mounting screw M13 x 1.25 128 to 137 13.0 to 14.0 94.1 to 101
Crankcase 2 flange screw M10 x 1.25 49 to 55 5.0 to 5.7 37 to 41
Item
Dimension x
Pitch
N·m kgf·m lbf·ft
Rocker arm bracket screw M10 x 1.25 49 to 55 5.0 to 5.7 37 to 41
*Cylinder head mounting screw
(Part number: 1G772-03450)
M14 x 1.5 187 to 196 19.0 to 20.0 138 to 144
*Cylinder head mounting screw
(Part number: 1J770-03450)
M14 x 1.5 165 to 175 16.9 to 17.8 122 to 129
Injection pump gear mounting nut
(left-handed screw)
M16 x 1.5 -LH 138 to 158 14.0 to 16.0 102 to 115
Oil cooler joint screw M20 x 1.5 40 to 44 4.0 to 4.5 29 to 32
Front cover mounting screw (7T) M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Front cover mounting screw (10T) M8 x 1.25 30 to 34 3.0 to 3.5 22 to 25
Flywheel housing mounting screw (9T) M12 x 1.25 103 to 117 10.5 to 12.0 76.0 to 86.7
Idle gear mounting screw (10T) M8 x 1.25 30 to 34 3.0 to 3.5 22 to 25
*Connecting rod screw M9 x 1.0 69 to 73 7.0 to 7.5 51 to 54
*Crankcase 2 mounting screw M14 x 1.5 138 to 147 14.0 to 15.0 102 to 108
Crankcase 2 flange screw (9T) M10 x 1.25 59 to 63 6.0 to 6.5 44 to 47
KiSC issued 06, 2020 A
