S-44
07-E3B SERIES, WSM
ENGINE
EGR Cooler and Flange (If necessary)
1. Remove the EGR cooler flange (2).
2. Remove the EGR cooler (4).
(When reassembling)
• Replace the gaskets (1) / (3) / (5) with new ones.
W1118406
EGR Valve and Reed Valve (If necessary)
1. Remove the EGR valve (1) from the EGR valve flange (5).
2. Remove the reed valve (3) from the EGR valve (1).
(When reassembling)
• Replace the gaskets (2) / (4) / (6) with new ones.
W1119991
(1) Gasket
(2) EGR Cooler Flange
(3) Gasket
(4) EGR Cooler
(5) Gasket
(6) EGR Valve
(1) EGR Valve
(2) Gasket
(3) Reed Valve
(4) Gasket
(5) EGR Valve Flange
(6) Gasket
KiSC issued 06, 2020 A
