Door Stop:
Pull the “Door Stop” button to raise the out-feed stop fro LEFT HAND doors. Push to
lower the out-feed stop.
Lock Location (Optional):
Shifts the lock machining carriage left or right depending on door hand.
Feed Mode (option):
Auto In:
Door will automatically clamp in position, operator manually unclamps and exits the
door.
Auto In / Out:
Door Only:
Automatically machines the door and out feeds the door.
Door & Jamb:
Automatically machines the door and jamb 1 second after jamb is
clamped.
Feed (Option):
Jog FWD:
Manually controls the feed belts, shifting toward the out feed end of the machine.
Jog REV.
Manually controls the feed belts, shifting toward the in feed end of the machine.
Start Sequence (FRONT/BACK) (option):
Front:
Activates the front section with out activating the back section (lock section)
Back:
Activates the back section for multi positioning for deadbolt, without activating the
front section (hinge routing).
