This page contains Kval, Inc. proprietary information and is not to be duplicated or disclosed to unauthorized persons.
37
Turn off Slide valve.
Put Front section turrets to middle position.
Put 2" Jamb pin in.
Adjust router tilt in height up 3/8"
Adjust 1/4" shim on top of spring for chipout tilt-in clearance.
Install 5/32" pins for jamb height.
Turn on slide valve
1 3/8" Door 3 1/2" Hinge 5/8" Radius
Turn off slide valve.
Put front section turrets on longest bolt position.
Put Jamb pin in 2 5/16"
Adjust router tilt in height down 3/8".
Adjust 1/4" shim on top of plate for chipout tilt in clearance.
Remove 5/32" pins for jamb height.
Turn on slide valve.
Commander Exterior Door Reveal Adjustment
The chipout block on the router carriage serves two functions; (1) to reference off the jamb, (2)
reference off the door. When changing either the reveal measurement, or the thickness of the door, it is
necessary to adjust the position of the chip out block relative to the new thickness and reveal
1/4" Radius
5/8" Radius
Hinge
Left Right Left
4 1/2" 1/4" 1 1/8" 5/8"
4" 1/2" 1 3/8" 7/8"
3 1/2" 3/4" 1 5/8" 1 1/8"
