Kval Commander - Setting up for a Cut Continued

This page contains Kval, Inc. proprietary information and is not to be duplicated or disclosed to unauthorized persons.
36
Standard Set Up
Cutter
Radius 3/16" 1/4" 5/16" 3/8"
1/4" 3/16" 1/4" 5/16" 3/8"
5/8" 9/16" 5/8" 11/16" 3/4"
With Cut through the Bottom Skin Set Up
* Optional - Requires modified H Blocks
Cutter
Radius 3/16" 1/4" 5/16" 3/8"
1/4" 1/2" 9/16" 5/8" 11/16"
5/8" 7/8" 15/16" 1" 1 1/16"
Jamb Backset: Top Pin
Cutter
Radius 1 1/8" Pocket 1 3/8" Pocket
1 5/8" Pocket
1/4" 2" 1 3/4" 1 1/2"
5/8" 2 3/8" 2 1/8" 1 7/8"
* 3 Degree Special Set-Up Information:
When cutting at 3 degrees you must subtract 1/32" from the Jamb
Pocket Top Pin AND Door Hinge Backset Bottom Pine.
From zero degrees to 3 degrees your overall pocket
decreases 1/16".
Setting Up For a Cut Continued
1 3/4" Door w/ 4" hinge 5/8" Radius
