Kwikset 264 - Step 3: Keypad and Mounting Plate Preparation; Prepare for Smaller Door Holes; Modify Mounting Plate for Fit

4 / 10 © 2016 Spectrum Brands, Inc.Kwikset: 1-800-327-5625 • www.kwikset.com
3
Prepare keypad and mounting plate (only for doors with smaller holes)
Diameter is 2-1/8" (54 mm) Diameter is 1-1/2" (38 mm)
21/8"
54 mm
11/2"
38 mm
No adjustment is required.
Proceed to step 4.
or
What is the diameter of the hole in the door?
A
B
Remove adapter ring from exterior assembly:
Use pliers to remove two tabs from mounting plate:
1. Remove gasket. 2. Remove adapter
ring from gasket.
3. Reinstall gasket,
ensuring tight seal.
D
G
