NOTE:
25.
26. Front carrier
27. Front
28.
29. Rear
Main switch
parking brake
Brake pedal(Only
MX'er 150/125)
carrier
The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
11
11
24 25 26 27 28
29
10
17 18 19 20 21 22 23
17. Throttle lever
18. Front Brake lever
19. R. Back mirror
20. Instruments
21. L. Back mirror
22. Rear Brake lever
23. Steering handlebar lock
(Only MX'er 150/125)
24. Rear parking brake
(Not all type)
