Transmission oil
1. Transmission oil replacement
A. Place the machine on a level place.
B. Place a container under the engine.
C. Remove the oil filler bolt and drain plug to
Drain the oil.
D. Reinstall the drain plug and tighten to
Specification.
1. Drain plug (MX'er 150/125)
1. Drain plug (MX'er 50)
Tightening torque
Drain plug:
MX'er 150/125: 23 Nm (2.3 m-kg, 17 ft-lb)
MX'er 50: 15 Nm (1.5 m-kg, 11 ft-lb)
92
