6. ENGINE REMOVAL/INSTALLATION
6-3
MXU 300/250
Remove the drive select shift to drive select
arm connecting bolt and nut.
Remove the two mounting nuts and drive
select shift.
Disconnect the speedometer cable.
Remove the three bolts at the drive sprocket
cover and then remove the drive sprocket
cover.
Remove the two bolts on the drive sprocket.
Remove the drive sprocket and washer.
N
uts
Bol
t
/Nu
t
Bolts
Drive Sprocket Cove
r
Bolts
Drive Sprocke
t
Speedometer Cable
