KYMCO MXU 300 - WHEELS;TIRES

3. INSPECTION/ADJUSTMENT
3-19
MXU 300/250
WHEELS/TIRES
Check the tires for cuts, imbedded nails or
other damages.
Check the tire pressure.
TIRE PRESSURE
1 Rider
Front 0.28 kgf/cm² (28 Kpa, 3.2 psi)
Rear 0.28 kgf/cm² (28 Kpa, 3.2 psi)
TIRE SIZE
Front: 22*7-10
Rear : 22*10-10
Check the front axle nut for looseness.
• Be sure that both tie-rod are turned the
same amount. If not, the machine will
drift tight or left even though the
handlebar is positioned straight which
may lead to mishandling and accident.
• After setting the toe-in to specification,
run the machine slowly for some
distance with hands placed lightly on
the handlebar and check that the
handlebar responds correctly. If not,
turn either the right or left tie-rod
within the toe-in specification.
＊
Tie-rod
Tie-rod End Nuts
Front Axle Nu
t
Tire pressure should be checked when
tires are cold.
＊
