6. ENGINE REMOVAL/INSTALLATION
6-5
MXU 300/250
Loosen the inlet hose band screw and then
disconnect the inlet hose from the left
crankcase cover.
Loosen the outlet hose band screw and then
disconnect the outlet hose from the left
crankcase cover.
Remove the rear lower mounting bolt and
nut.
Remove the rear upper mounting bolt and
nut.
Remove the front mounting bolts and nuts.
Remove the four bolts for remove the left
and right engine brackets.
Mounting Bolt and Nu
