6. ENGINE REMOVAL
6-8
MXU 300/ 250
ENGINE REMOVAL (MXU 300)
Drain engine oil and transmission oil.
(Refer to chapter 3).
Remove frame covers and exhaust pipe.
(Refer chapter 2).
Remove the air cleaner housing and
carburetor. (Refer to chapter 5).
Disconnect the spark plug from the cylinder
head.
Disconnect the spark coil connectors from
the spark coil, then remove the two bolts
and spark coil.
Disconnect the speedometer cable.
Disconnect the crankcase breather from the
cylinder head cover.
Disconnect the vacuum hose from the inlet
pipe.
Bolts Connectors
Spark Plug Spark Coil
Speedometer Cable
Speedometer Cable
Vacuum Hose
