9.DRIVE AND DRIVEN PULLEYS
9-5
MXU 300/250
Remove the left crankcase cover. (Refer to
the “LEFT CRANKCASE COVER
REMOVAL” section in the chapter 9)
Remove the drive pulley. (Refer to the
“DRIVE PULLEY REMOVAL” section in
the chapter 9)
Hold the clutch outer with the universal
holder and remove the clutch outer nut.
Special tool: Universal Holder E017
Remove the collar and clutch outer.
Remove the clutch/driven pulley and drive
belt.
N
u
t
Universal Holde
r
Colla
r
Clutch Oute
r
Clutch/Driven Pulley
Drive Bel
t
