14. FRONT WHEEL/FRONT SUSPENSION/
STEERING SYSTEM
14-7
MXU 300/250
Install the right new bearing and dust seal
into the front wheel hub.
Special tool:
Oil seal and bearing install E014
INSTALLATION
Reverse the “FRONT WHEEL HUB
REMOVAL AND INSPECTION”
procedures.
Tighten the front wheel hub nut.
Torque: 7 kgf-m (70 Nm, 50 lbf-ft)
Install the cotter pin and band ends of cotter
pin.
Always use a new cotter pin.
＊
Do not loosen the wheel hub nut after
torque tightening. If the wheel hub nut
groove is not aligned with the cotter pin
hole, align groove with the hole by
tightening up on the wheel hub nut.
Always use a new cotter pin.
＊
Apply the grease onto the oil seal lips,
bearing.
＊
Apply grease onto the bearing and dust
seal lips of the wheel panel.
＊
• Do not allow the bearings to tilt while
driving them in.
• Do not strike the center race or balls of
the bearing. Contact should be made
only with the outer race.
• Pack all bearing cavities with grease.
• Drive in the bearing squarely with the
sealed end facing out.
＊
To Next Page
