14. FRONT WHEEL/FRONT SUSPENSION/
STEERING SYSTEM
14-22
MXU 300/250
Remove the cotter pins and nuts attaching
the tie-rods, then disconnect the tie-rods
from the steering column.
Remove the cotter pin and nut attaching the
steering column under the frame body, then
remove steering column and collar.
Inspect the collar, dust seals, snap ring
(under the dust seal) and bearing.
Wear/damage →Replace.
Cotter Pin
N
u
t
Cotter Pin
N
u
t
Dust SealColla
r
Bearing
Dust Seal
Snap Ring
