Kyocera Ecosys FS-1320D Technical Reference Manual

Diablo 630 Emulation (Mode 2)
7-13
Fonts can be selected by placing font commands in the file to be printed, or using SETF
(set alternate font) and ALTF (change to alternate font) commands. To substitute scalable
fonts for the embedded fonts using SETF command, employ the FSET command to
apply the appropriate font number for that scalable font. The default font mode (FTMD)
is 0, so the printing system will not adjust character spacing, line spacing, or page orien-
tation.
The red/black ribbon feature of the Diablo 630 printer is implemented in an interesting
way. The printing system translates the black ribbon command internally into an ALTF 0
command, and the red ribbon command into an ALTF 1 command. It also uses two pairs
of SETF default values:
Accordingly, if you use the embedded command that asks for red ribbon, you will get
bitmap font 2, Dutch801BM10-Roman, which the printing system emulates using a resi-
dent scalable font. This font is proportionally spaced, so you should also specify propor-
tional spacing with an embedded command. When you change back to black ribbon, the
printing system changes to bitmap font 1, CourierBM12-Roman, also emulated using a
scalable font.
With SETF commands you can select any two fonts you like which correspond to the
black and red ribbons. For example, you can have black mean normal CGTimes and red
mean CGTimes italicized. The appropriate setup is shown below, together with a short
file and the printed result.
!R!
SFNT ’CGTimes’, 10, 3000;
SFNT ’CGTimes-It’, 10, 3001;
SETF 1, 3000; CMNT Red: 10-point CGTimes;
SETF 0, 3001; CMNT Black: 10-point CGTimes Italic;
EXIT;
^[A10,000 Maniacs: ^[BOur Time in Eden ^[A(Elektra)
^[AGarth Brooks: ^[BThe Chase ^[A(Liberty)
^[ARed Hot Chill Peppers: ^[BWhat Hits!? ^[A(EMI)
For red-ribbon, put ESC A (^[A in binary notation) at the point you would start to print
in normal CGTimes, and put ESC B (^[B in binary notation) at the point to end using the
font.
Figure 7. 8. Diablo Font Printout
Ribbon color Simulated bitmap font SETF default value
Black CourierBM12-Roman SETF 0, 1;
Red Dutch 801BM10-Roman SETF 1, 2;

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
