Kyocera Ecosys FS-1320D Technical Reference Manual

HP 7550A Emulation [KC-GL] (Mode 8)
7-97
The SM (Symbol Mode) instruction defines the first succeeding character as a symbol
character. The DT (Define label Terminator) instruction defines the first succeeding
character as a character plot terminator.
The character plot terminator is used to terminate the LB (LaBel) instruction. The default
terminator is the ETX character (End of Text), which uses ASCII code 3. If this termina-
tor is inconvenient, the DT instruction enables the user to change the character plot ter-
minator to a different character.
Parameter Formats
KC-GL parameters are specified in one of the following formats:
Integer
When not scaled, integers are valid in the range from –2
23
to 2
23
–1 plotter units. Digits
to the right of the decimal point are ignored. If no sign is specified, the value is assumed
to be positive.
Real number (decimal)
Real numbers from –2
23
to 2
23
–1 are valid. They can include up to eight digits to the
right of the decimal point. If no sign is specified, the value is assumed to be positive.
Scaled real number (scaled decimal)
Real numbers from –2
23
to 2
23
–1 can be used with up to eight digits to the right of the
decimal point. If no sign is specified, the value is assumed to be positive. Scaled real
numbers are used only with scaled user units. All KC-GL parameters that are interpreted
as user units are scaled.
Character string
A combination of characters, numeric expressions, and string variables.
When coding an instruction with two or more parameters (Examples: PA, PR, PU, PD)
remember that the parameters must be set apart by a separator.
KC-GL Environment Options
The FRPO G0 command establishes various options for the KC-GL environment. The
following table lists the meanings of the individual bits in the command. Each meaning
is explained in the following sections according to the bit position.
Table 7.28. FRPO G0 Command Options
Bit Position Bit Value Logic Value Description
0 0 0 Plot coordinate mode A
1 1 Plot coordinate mode B
1 0 0 Form feed in response to SP
2 1 SP
2 0 0 Automatic plot coordinate transition
4 1 Fixed plot coordinate
3 0 0 Normal mode
8 1 Enhance mode

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
