Kyocera Ecosys FS-1320D Technical Reference Manual

HP 7550A Emulation [KC-GL] (Mode 8)
7-111
Summary of KC-GL Instructions
The table below lists KC-GL instructions supported by the printing system. The follow-
ing legend is used:
[c] Character string
[d] decimal (-128.0000 to +127.9999)
[i] integer (-32768 to +32767)
[sd] scaled decimal (-32768.0000 to +32767.9999)
Coordinate Values, Mode B, RO 90
Paper size P1x P1y P2x P2y
A4 –2480, –4700 2480, 4700
A3 –4700, –6680 4700, 6680
Letter –2598, –4348 2598, 4348
Ledger –4348, –6916 4348, 6916
Table 7.38. KC-GL Instructions (Sheet 1 of 2)
Instruction Parameters Description
AA x-coordinate [i/sd], y-coordinate [i/sd],
center-angle [i] (, resolution [i])
Arc absolute
AF – Advance page
AH – Advance page
AR Δx [i/sd], Δy [i/sd], arc-angle [i] (, resolution [i]) Arc relative
BL character-string [c] terminator Buffer label
CA character-set-no. [i] Designate alternate character set
CI radius [i/sd] (, resolution [i]) Circle
CP horizontal-character-count [d],
vertical-character-count [d]
Character plot
CS character-set-no. [i] Designate standard character set
CT – Chord tolerance for AA, AR, CI
DF – Default
DI run [d], rise [d] Absolute direction
DR run [d], rise [d] Relative direction
DT terminator [c] Define label terminator
EA x-coordinate [i/sd], y-coordinate [i/sd] Edge rectangle absolute
EP – Edge polygon for PM, RA, RR, WG
ER Δx [i/sd], Δy [i/sd] Edge rectangle relative
ES character-space [d](, line- space [d]) Extra space for NCP
EW radius [i/sd], start-angle [i],
center-angle [i] (, resolution [i])
Edge wedge
FP – Fill polygon for PM, RA, RR, WG
FT type [i] (,spacing [sd] (,angle [i])) Fill type
IM E-mask-value [i] (, S-mask-value [i] (,P-mask-
value [i]))
Input mask
IN – Initialize
IP P1x [i], P1y [i] (, P2x [i], P2y [i]) Input P1 and P2
IW X
LL
[i/sd], Y
LL
[i/sd], X
UR
[i/sd], Y
UR
[i/sd], Input window
LB character-string [c] Label
LO position-number [i] Label origin
LT pattern-no. [i] (, pattern-length [d]) Line type
OA – Output actual position and pen
status*

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
