Kyocera Ecosys FS-1320D Technical Reference Manual

Chapter 7 Emulation
7-138
CollateDetails Parameters
CollateDetails has the following parameters as tabled below according to the key of
operations. By making /Collate true, CollateDetails enables the printing system to
implement the e-MPS function according to the keys explained in the following table.
Programming with CollateDetails for Job Retention
CollateDetails enables the printing system to implement the e-MPS Job Retention func-
tion in KPDL mode. The /Mode key must be set to true for all of these functions. The
b
SorterDetails can specify tray arrangement and sorter operation mode as the following example:
<< /SorterDetails << /SorterTray[1 2]/SorterMode(SORTER)>> >>
setpagedevice
Tray arrangement array of [1 2] specifies tray 1 and tray 2 to be used. If tray numbers are omitted ([
]), all trays are used. Sorter mode string of (SORTER) specifes sorter mode. Other options include
(COLLATOR) and (MAILBOX).
c
A typical StapleDetails sequence is as follows. To staple each 20 pages at position 3 on the page:
<< /Staple 3 /StapleDetails << /StaplePosition 3 /Count 20 >> >>
setpagedevice
d
To punch in sub style, use the following example:
<< /Punch 3 /PunchDetails << /PunchMode 2 >> >> setpagedevice
Table 7.50. CollateDetails Parameters
Key Type Meaning Parameters default
/Mode integer Job mode 0: HP Mopier mode/Job retention
1: Volatile job
2: Nonvolatile job
8: VirtualMailbox job
0
/Type integer Job Retention enable 8: Enable Job Retention —
/Hold integer Job Retention mode 1: QuickCopy
2: Stored job
3: Proof and Hold
—
/HoldType integer Job Retention security 0: No security
1: Security with PIN code
0
/HoldKey integer PIN code Number of 4 bytes —
/Barcode integer Barcode output 0: Output on first page
1: Output on all pages
2: Do not output
2
/BarcodePosition integer Barcode printing position
(viewed in portrait
orientation)
0: Lower right (bar only)
1: Lower right perpendicular (bar only)
2: Upper right perpendicular (bar only)
3: Upper right (bar only)
4: Upper left (bar only)
5: Upper left perpendicular (bar only)
6: Lower left perpendicular (bar only)
7: Lower left (bar only)
128: Lower right (bar + ID)
129: Lower right perpendicular (bar + ID)
130: Upper right perpendicular (bar + ID)
131: Upper right (bar + ID)
132: Upper left (bar + ID)
133: Upper left perpendicular (bar + ID)
134: Lower left perpendicular (bar + ID)
135: Lower left (bar + ID)
0
/Share integer Share flag 0: Shared
1: Not shared
0
/Name string Job name Character string up to 31 bytes maximum ()
/User string User name Character string up to 31 bytes maximum ()
/Time string Time stamp Character string up to 31 bytes maximum ()
/Destination array VMB destination — []

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
