Kyocera Ecosys FS-1320D Technical Reference Manual

Chapter 7 Emulation
7-12
Diablo 630 Emulation (Mode 2)
To set the power-up emulation for Diablo 630, send the printing system the following
PRESCRIBE command sequence:
!R! FRPO P1, 2; FRPO P3, 1; EXIT;
The Diablo uses ten symbol sets as shown below. To select one of these symbol sets, use
the INTL command or the operator panel keys. Permanent setting of the symbol set is
made with the FRPO U6 and U7 parameters.
The factory setting for the symbol set at power-up is IBM PC-8 for all emulation modes.
The U0—U3 parameters of the FRPO command will be ignored in the Diablo emulation.
The line and character spacing are always 6 lines and 10 characters per inch at power-up
and after a reset.
In Diablo emulation, the printing system supports the embedded commands of word-pro-
cessing software essentially the same way as the Diablo 630 printer does for the follow-
ing features:
• Margins
• Horizontal and vertical tabulation
• Line and character spacing, including proportional spacing
• Half line feed, reverse line feed, and reverse half line feed
• Backspace and fine backspace
• Bold (shadow), double-strike, and underlining
• Graphics mode
Note
If you attempt to print beyond the right margin, the characters will not be printed.
A feature the printing system has that the Diablo does not is the landscape orientation. To
print in landscape orientation, send the command SPO L; and select a landscape font.
Example:
To print in landscape, send the following command:
!R! SPO L; EXIT;
The automatic centering, justification and Hyplot mode of the Diablo printer are not sup-
ported.
Table 7.7. Diablo 630 Emulation Symbol Sets
Symbol set Message display FRPO commands
US DIABLO US FRPO U6, 0; FRPO U7, 2;
France DIABLO France FRPO U6, 1; FRPO U7, 2;
Germany DIABLO Germany FRPO U6, 2; FRPO U7, 2;
UK DIABLO U.K. FRPO U6, 3; FRPO U7, 2;
Denmark DIABLO Denmark FRPO U6, 4; FRPO U7, 2;
Sweden DIABLO Sweden FRPO U6, 5; FRPO U7, 2;
Italy DIABLO Italy FRPO U6, 6; FRPO U7, 2;
Spain DIABLO Spain FRPO U6, 7; FRPO U7, 2;
Japan DIABLO Japan FRPO U6, 8; FRPO U7, 2;
US Legal US Legal FRPO U6, 9; FRPO U7, 2;

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
