Kyocera Ecosys FS-1320D Technical Reference Manual

Chapter 7 Emulation
7-58
Raster Graphics
Raster
Resolution
75 dots/inch
ESC
*t75R 1B 2A 74 37 35
52
YesYesYesYesYes
100 dots/inch
ESC
*t100R 1B 2A 74 31 30
30 52
YesYesYesYesYes
150 dots/inch
ESC
*t150R 1B 2A 74 31 35
30 52
YesYesYesYesYes
200 dots/inch
ESC
*t200R 1B 2A 74 32 30
30 52
No Yes No Yes Ye s
300 dots/inch
ESC
*t300R 1B 2A 74 33 30
30 52
YesYesYesYesYes
600 dots/inch
ESC
*t600R 1B 2A 74 36 30
30 52
No Yes No Yes Yes
Orientation
Raster Graphics
Raster
Graphics
Presentation
Follows
orientation
ESC
*r0F 1B 2A 72 30 46 Yes Yes Yes Yes Yes
Follows
physical page
ESC
*r3F 1B 2A 72 33 46 Yes Yes Yes Yes Yes
Start Raster
Graphics
Left Raster
Graphics
Margin
ESC
*r0A 1B 2A 72 30 41 Yes Yes Yes Yes Yes
Current
Cursor
ESC
*r1A 1B 2A 72 31 41 Yes Yes Yes Yes Yes
Scale mode
(logical left
page
boundary)
ESC
*r2A 1B 2A 72 32 41 No No No No Yes
Scale mode
(at CAP)
ESC
*r3A 1B 2A 72 33 42 No No No No Yes
Raster Y
Offset
# of Raster
Lines of
vertical
movement
ESC
*b#Y 1B 2A 62 #...#
59
YesYesYesYesYes
Set Raster
Compression
Mode
Unencoded
ESC
*b0M 1B 2A 62 30 4D Yes Yes Yes Yes Yes
Run-Length
Encoded
ESC
*b1M 1B 2A 62 31 4D Yes Yes Yes Yes Yes
Tagged Image
File Format
ESC
*b2M 1B 2A 62 32 4D Yes Yes Yes Yes Yes
Delta Row
ESC
*b3M 1B 2A 62 33 4D Yes Yes Yes Yes Yes
Adaptive
compression
ESC
*b5M 1B 2A 62 35 4D Yes Yes Yes Yes Yes
Replacement
Delta Row
ESC
*b9M 1B 2A 98 39 4D Yes Yes Yes Yes Yes
Transfer
Raster Da
ta by
row
# of Bytes
ESC
*b#W
[Data]
1B 2A 62 #...#
57
YesYesYesYesYes
Transfer
Raster Data
(by plane)
# of Bytes
ESC
*b#V
[Data]
1B 2A 98 #...#
56
No No No No Yes
End Raster
Graphics
Old version
ESC*
rB 1B 2A 72 42 Yes Yes Yes Yes Yes
Preferred
ESC
*rC 1B 2A 72 43 Yes Yes Yes Yes Yes
Raster Height
(Source)
# Raster Rows
ESC
*r#T 1B 2A 72 #...#
54
YesYesYesYesYes
Raster Width
(Source)
# Pixels of the
Specified
Resolution
ESC
*r#S 1B 2A 72 #...#
53
YesYesYesYesYes
THE PRINT MODEL
Imaging
Table 7.25. HP LaserJet PCL Commands (Sheet 10 of 15)
Function Parameter Command Hexadecimal
Value
1000
1000+
1800
1900
3800
6300
6750
6900
9100DN
9500DN
8000C

Kyocera Ecosys FS-1320D Specifications

General

Ethernet LAN	No
Network ready	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	IBM ProPrinter, PCL 5c, PCL 6, PostScript 3
Processor model	405F5
Processor family	PowerPC
Maximum internal memory	544 MB
Display	LED
Certification	TÜV/GS, CE, PTS, C-Tick
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	USB 2.0
Optional connectivity	Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.2 W
Power consumption (printing)	544 W
Power consumption (PowerSave)	4.3 W
Media thickness	0.11 mm
Compatible operating systems	Windows OS Linux OS Unix OS Mac OS X 10.2+

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
