Operation Panel
4-58
IPv4 Setting (TCP/IP IPv4 settings)
This selects the settings for TCP/IP (IPv4).
1
In the TCP/IP Settings menu, press or to select IPv4
Setting.
2
Press [OK]. The IPv4 Setting menu screen appears.
The options available in the TCP/IP (IPv4) settings are as follows:
• DHCP (DHCP setting)...4-58
• Auto-IP (Auto-IP setting)...4-58
• IP Address (IP address setting)...4-59
• Subnet Mask (Subnet mask setting)...4-59
• Default Gateway (Gateway setting)...4-60
• Bonjour (Bonjour setting)...4-60
IMPORTANT The DHCP, Auto-IP, IP address, subnet mask, default
gateway and Bonjour menu options for IPv4 settings are displayed
when TCP/IP is enabled.
DHCP (DHCP setting)
DHCP (Dynamic Host Configuration Protocol) is the protocol that assigns the information required to establish a network
connection when a host attempts to connect to the network (Internet). This information includes the IP address of the local
node and the default router (the router in the host's own network system) and the DNS (Domain Name System) server.
DHCP is an extension of the BOOTP (Bootstrap) startup protocol.
1
In the IPv4 Setting menu, press or to select DHCP.
2
Press [OK]. The DHCP screen appears.
3
Press or to select whether DHCP is enabled.
4
Press [OK]. The DHCP setting is set and the IPv4 Setting menu
reappears.
Auto-IP (Auto-IP setting)
This protocol is used for automatic assignment of an IP address when you connect to a small network that does not have
a DHCP server. Select an address from the range 169.254.0.1 to 169.254.255.254, and if no other device on the network
is using that address, it is used as your address.
1
In the IPv4 Setting menu, press or to select Auto-IP.
2
Press [OK]. The Auto-IP screen appears.
To Next Page
