Kyocera ECOSYS M2540dw User Manual

3-10
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
Creating a Shared Folder, Making a Note of a Shared
Folder
Create a shared folder to receive the document in the destination computer.
1
Create a folder.
Create a folder on your computer.
For example, create a folder with the name "scannerdata" on the desktop.
NOTE
If there is a workgroup in System Properties, configure the settings below to limit folder access to a specific user or group.
1 Select [Settings] in charms on Desktop, and select [Control Panel], [Appearance and
Personalization], and then [Folder Options].
In Windows XP, click [My Computer] and select [Folder Options] in [Tools].
In Windows 7, from [Start] button on the Windows, select [Control Panel], [Appearance
and Personalization], and then [Folder Options].
In Windows 10, open up a window in File Explorer and select [View], [Options], and then
[Folder Options].
2
Remove the checkmark from [Use Sharing Wizard (Recommended)] in "Advanced
settings".
In Windows XP, click the [View] tab and remove the checkmark from
[Use Simple File Sharing (Recommended)] in "Advanced settings".
1
2
3
Make sure that the [View] tab is selected.

Kyocera ECOSYS M2540dw Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Fax Capability	Yes
Standard Paper Capacity	250 sheets
Max Paper Capacity	850 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Processor	800 MHz
Dimensions	417 x 412 x 437 mm
Weight	19 kg
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm
Scan Type	Color
Copy Speed	Up to 40 cpm (A4)
Connectivity	USB 2.0, Ethernet, Wi-Fi
First Print Out Time	6.4 seconds
First Copy Out Time	6.4 seconds
Scan Speed	40 ipm
Paper Input Capacity	250 sheets
Paper Output Capacity	150 sheets
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Interface	USB 2.0, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, KYOCERA Mobile Print
