Kyocera ECOSYS M2540dw User Manual

2-42
Installing and Setting up the Machine > Installing Software
Setting WIA Driver
Register this machine to the WIA Driver. Instructions are based on interface elements as they appear in Windows 8.1.
1
Display the screen.
1 Click [Search] in charms, and enter "View scanners and cameras" in the search box.
Select [View scanners and cameras] in the search list then the Scanners and Cameras
screen appears.
2 Select the same name as this machine from WIA Drivers, and click [Properties].
2
Configure WIA Driver.
NOTE
In Windows 7, click [Start] button on the Windows and enter [Scanner] in [Program and
File Search]. Click [View scanners and cameras] in the search list then the Scanners
and Cameras screen appears.
1 Click the [Settings] tab.
2 Enter the machine IP addresses or host
name.
3 When using SSL, select the checkbox
beside SSL.
4 Set units of measurement.
5 Click [OK].
1 Click the [Settings] tab.
2 Set the Compression Level.
3 Set units of measurement.
4 Click [OK].
1
2
(Network) (USB)
1
2
3
4
1
2
5
3
4

Kyocera ECOSYS M2540dw Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Fax Capability	Yes
Standard Paper Capacity	250 sheets
Max Paper Capacity	850 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Processor	800 MHz
Dimensions	417 x 412 x 437 mm
Weight	19 kg
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm
Scan Type	Color
Copy Speed	Up to 40 cpm (A4)
Connectivity	USB 2.0, Ethernet, Wi-Fi
First Print Out Time	6.4 seconds
First Copy Out Time	6.4 seconds
Scan Speed	40 ipm
Paper Input Capacity	250 sheets
Paper Output Capacity	150 sheets
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Interface	USB 2.0, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, KYOCERA Mobile Print
