4-10
Printing from PC > Printing Data Saved in the Printer
Printing Data Saved in the Printer
You can save the print job into the Job Box of this device and print it as necessary. To use the Stored Job Box and the
Quick Copy Box, an SD/SDHC memory card must be installed in the device.
If you configure settings in the [Job] tab of the printer driver and then print, the print job will be saved in the Job Box
(memory) and printing can be executed at the machine.
Follow the work flow below when using Job Box.
Specifying the Job Box from a computer and sending the print job. (page 4-10
)
Using the operation panel to specify a file within a Box and printing it.
You can print the documents from the following boxes.
Printing Documents from Private Print Box (page 4-11)
Printing Document from Stored Job Box (page 4-12)
Printing Document from Quick Copy Box (page 4-14)
Printing Document from Proof and Hold Box (page 4-15)
Specifying the Job Box from a Computer and Storing
the Job
1
Click [File] and select [Print] in the application.
The Print dialog box displays.
2
Select the machine from the "Name" menu.
3
Click the [Properties] button.
The Properties dialog box displays.
4
Click the [Job] tab and select the [Job storage (e-MPS)] check
box to set the function.
IMPORTANT
Unencrypted data is saved on the SD/SDHC memory card.
Exercise caution when saving sensitive documents.
NOTE
• To use the Private Print Box and the Proof and Hold Box, [RAM Disk Mode] must be [On].
RAM Disk Mode (page 8-30)
• If you are using an SD/SDHC memory card to use a Job Box, set [RAM Disk Mode] to [Off].
NOTE
For information on how to use the printer driver software, refer to the following:
Printer Driver User Guide

Table of Contents

Other manuals for Kyocera ECOSYS M2540dw

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS M2540dw and is the answer not in the manual?

Kyocera ECOSYS M2540dw Specifications

General IconGeneral
Print TechnologyLaser
Print Resolution1200 x 1200 dpi
Duplex PrintingYes
Fax CapabilityYes
Standard Paper Capacity250 sheets
Max Paper Capacity850 sheets
FunctionsPrint, Copy, Scan, Fax
Copy Resolution600 x 600 dpi
Scan Resolution600 x 600 dpi
Processor800 MHz
Dimensions417 x 412 x 437 mm
Weight19 kg
Operating System CompatibilityWindows, Mac OS, Linux
Print Speed40 ppm
Scan TypeColor
Copy SpeedUp to 40 cpm (A4)
ConnectivityUSB 2.0, Ethernet, Wi-Fi
First Print Out Time6.4 seconds
First Copy Out Time6.4 seconds
Scan Speed40 ipm
Paper Input Capacity250 sheets
Paper Output Capacity150 sheets
Supported Paper SizesA4, A5, A6, B5, Letter, Legal
InterfaceUSB 2.0, Ethernet, Wi-Fi
Mobile PrintingApple AirPrint, KYOCERA Mobile Print
