5-6
Operation on the Machine > Connecting cable
2
Place the originals.
1 Put the side to be scanned (or the first side of two-sided originals) face-up. Slide the leading edge into the
document processor as far as it will go.
2 Open the original stopper to fit the size of the original set (Original size: A3 or Ledger).
For details on Original Orientation, refer to the following:
[Original Orientation] (6-9)
Confirm that the original width guides exactly fit the originals. If there is a gap, readjust the original
width guides. The gap may cause the originals to jam.
Ensure that loaded originals do not exceed the level indicator. Exceeding the maximum level may
cause the originals to jam.
Originals with punched holes or perforated lines should be placed in such a way that the holes or
perforations will be scanned last (not first).
To Next Page
