Installing and Setting up the Machine > Part Names

With Optional Equipments Attached

1 Cassette 2

2 Cassette 3

3 Cassette 4

4 Manual stapler

5Rear Cover 2

6Rear Cover 3

7Rear Cover 4

Optional Equipment (page 11-2)
