Kyocera ECOSYS MA2100cfx User Manual

3-14
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
5 Specify the location.
6 Set the access permission for the user selected.
7 Click the [OK] button in the "Advanced Sharing" screen to close the screen.
1 If the computer name that you made a note of on page is the same as the domain
name:
If the computer name is not shown in "From this location", click the [Locations] button,
select the computer name, and click the [OK] button.
Example: PC001
If the computer name that you made a note of on page is not the same as the domain
name:
If the text after the first dot (.) in the full computer name that you made a note of does
not appear in "From this location", click the [Locations] button, select the text after the
dot (.), and click the [OK] button.
Example: abcdnet.com
Making a note of the user name and domain name
(page 3-11)
2 Enter the user name that you made a note of on page in the text box, and click the [OK]
button.
Also the user name can be made by clicking the [Advanced] button and selecting a
user.
NOTE
"Everyone" gives sharing permission to everyone on the network. To strengthen
security, it is recommended that you select "Everyone" and remove the "Read" [Allow]
checkmark.
2
1
1
2
3
1 Select the user you entered.
2 Select the [Allow] checkbox of the
"Change" and "Read" permissions
3 Press [OK].

Kyocera ECOSYS MA2100cfx Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Automatic Document Feeder (ADF)	Yes (50 sheets)
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	417 x 429 x 495 mm
Duplex Printing	Automatic
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Functions	Print, Copy, Scan
Weight	26 kg
Print Speed (Black)	Up to 21 ppm (A4)
Print Speed (Color)	Up to 21 ppm (A4)
Copy Speed	Up to 21 cpm (A4 Black/Color)
