2-18
Installing and Setting up the Machine > Network Setup
Network Setup
Configuring the Wired Network
The machine is equipped with network interface, which is compatible with network protocols such as TCP/IP (IPv4),
TCP/IP (IPv6), NetBEUI, and IPSec. It enables network printing on the Windows, Macintosh, UNIX and other platforms.
Set up TCP/IP (IPv4) to connect to the Windows network.
Be sure to connect the network cable before configuring the settings.
Connecting LAN Cable
(page 2-8)
For other network settings, refer to the following:
Network Setting
(page 8-7)
IPv4 setting
1
Display the screen.
[System Menu/Counter] key > [ā²] [ļ±] key > [System/Network] > [OK] key > [ā²] [ļ±] key >
[Network Setting] > [OK] key > [ā²] [ļ±] key > [Wired Netwk. Set] > [OK] key > [ā²] [ļ±] key >
[TCP/IP Settings] > [OK] key > [ā²] [ļ±] key > [IPv4 Setting] > [OK] key
2
Configure the settings.
When setting the static IP address
1 [ā²] [ļ±] key > [DHCP] > [OK] key > [ā²] [ļ±] key > [Off] > [OK] key
2 [ā²] [ļ±] key > [IP Address] > [OK] key
3 Set the IP address.
4 Select the [OK] key.
5 [ā²] [ļ±] key > [Subnet Mask] > [OK] key
NOTE
If user login administration is enabled, you can only change the settings by logging in with administrator privileges.
If user login administration is disabled, the user authentication screen appears. Enter a login user name and
password, and select [Login].
The factory default login user name and login password are set as shown below.
Login User Name: 2100
Login Password: 2100
NOTE
You can set any value between 000 and 255.
Use the numeric keys or select the [ā²] or [ā¼] key to enter a number.
Select the [ā] or [āŗ] key to move the position being entered, which is shown highlighted.
To Next Page
